1. Description

 DIHORSE DH-L960 CO2 Engraving and Cutting Machine offers precise and aesthetical engraving and cutting of non-metal materials. It is suitable for both home and commercial purposes, and widely used for fine engraving and cutting, hollow carving of acrylic, leather, paper,  MDF, rubber, organic board, two-color board, wood board, bamboo products, glass,  cloth, resin, plastic, rubber, ceramic tile, crystal, bamboo, organic glass and other non-metallic materials with various texts, graphics, images, trademarks, etc.

You have different laser powers and working sizes options, contact our online sales rep. for the advice of a suitable one.

2. Features

• Cover Open Protection: it will automatically cut off the power when the cover is open, which protects the human beings from radiation or hurt by the laser, increasing the safety, stability, and reliability of use and maintenance.
• Water Cooling Protection: to avoid the damage of the laser tube due to high temperature, the machine will not work if the water chiller is not connected.

• Red-dot Positioning: the machine uses a red light indication method to achieve precise positioning of the laser beam.
• Breakpoint Continuous Engraving: it will continue working from breakpoint after the power is on again.

• Worktime Preview Function: it can demonstrate real working time with accuracy up to the millisecond level, and also support dynamic display of machining path and coordinate points, real-time display and tracking of machining progress.

3. Parameters

Model	DH-L960
Working area	900*600mm
Laser tube type	Hermetic CO2 glass tube
Laser tube watts	80w RECI laser tube
Control software	RDC6445g
Rail guide	Taiwan PMI rail guide
Emergency stop	French Schneider
Belt	Shanghai Fulong belt(1.5cm)
Water cooling	CW3000 water chiller
Positioning accuracy	0.05mm
Resolution	4500dpi
Cutting speed	36000mm/min
Engraving speed	60000mm/min
Intelligent memory	Store unlimited files up to 128M
Interface	USB 2.0
Compatible software	Coredraw, Autocad, Photoshop
Graphic format support	TIFF, BMP, GIF, JPEG, TGA, AFX, etc
Minumum character	English 1*1mm
Electrical requirements	AC 110v 50Hz
Print interface	Ethernet or USB interface, compatible with Windows XP/7/8/10

Cutting Thickness

CO2 Laser  Cutting thickness
Max cutting thickness	80w	100w	130w	150w
Arcylic	15mm	18mm	20mm	25mm
MDF	5mm Write a review Please login or register to review DIHORSE DH-L960 80W/100W CO2 Laser Engraving and Cutting Machine Product Code:DH-L960 Availability:In Stock $30,300.00 Available Options Co2 power 80 W 100 W (+$200.00) Qty Add to Cart 0 reviews / Write a review
